Disc Filter | Cluster Filters |Stainless Steel
The disc cluster filter range from Ultratec Water Treatment LLC covers Aytok disc filters and multi-cartridge cluster filters in FRP and stainless steel. These systems remove suspended solids from feed water and are widely used as pretreatment for RO plants, cooling systems, irrigation and process water. Whether you need a disc cartridge filter in UAE or a stainless steel cluster filter for high-flow duty, we supply the right configuration for your site.
Key Features
- Disc or screen cartridge options with 20 to 125 micron ratings
- Stainless steel cluster housing in SS304, with SS316 on request
- Multi-cartridge design for higher flow rates
- Flanged inlet and outlet options
- Entire cartridge set removes at once for quick cleaning or replacement
- Corrosion-resistant, low-maintenance construction for continuous operation
Technical Specifications
Specification | Aytok Disc Filter | FRP Cluster Filter | Stainless Steel Cluster Filter |
Body / Housing Material | PA 30% GFR | FRP | SS304 (SS316 on request) |
Cartridge Material | PP disc, PA screen with AISI 304 cage | Filter cartridges | Filter cartridges |
Filtration Degree | 20 / 50 / 100 / 125 micron | Various micron ratings | Various micron ratings |
Max. Working Pressure | 8 bar (116 psi) | As per design | As per design |
Working Temperature | Up to 60 °C (140 °F) | 1 to 35 °C | 1 to 50 °C |
Connection | Various sizes | Flange in/outlet | Flange in/outlet |
Model
Features
- Disc or screen cartridge options
- Filtration ratings from 20 to 125 microns
- Glass fibre reinforced body construction
- Compact modular design
- Corrosion-resistant materials
- Suitable for continuous operation
- Easy cartridge removal for cleaning
- Low maintenance requirements
- Available in multiple sizes
- Suitable for industrial and irrigation applications
Available Options
- Manual or automatic cleaning
- Different micron ratings
- Screen cartridge configuration
- Multiple filter manifolds
- Various connection sizes
- Skid-mounted assemblies
- Pressure gauges
- Automatic flushing controls
Ideal Applications
- RO plant pretreatment, including alkaline and drinking water RO units such as Evo Pure alkaline RO
- Irrigation and agricultural water
- Cooling water and industrial process water
- Food, beverage, pharmaceutical and chemical processing
Why Choose Us
Ultratec Water Treatment Equipment LLC is an ISO 9001:2015 certified company based in Dubai, and a trusted disc filter supplier in UAE. We select the right filter for your feed water, flow rate and micron requirement, using components from certified global manufacturers. Our team also provides installation, commissioning and after-sales support across the UAE.
Buy Disc Cluster Filter in UAE
Looking for a dependable cluster cartridge filter or disc filter at a competitive price? Ultratec supplies standard and custom-built units, from single filters to skid-mounted assemblies.
- Free quotation and technical selection support
- Spare cartridges and disc elements in stock
- Delivery across Dubai, Abu Dhabi, Sharjah and and all UAE
Frequently Asked Questions
A Disc Filter uses stacked filter discs to capture suspended particles, while a Cluster Filter uses multiple filter cartridges housed within a single vessel. The suitable option depends on the required filtration process, flow rate, and water quality.
These systems are widely used in irrigation, reverse osmosis pretreatment, manufacturing, food and beverage processing, chemical industries, cooling water systems, commercial buildings, municipal water treatment, and industrial process water applications.
Selection depends on several factors, including feedwater quality, required micron rating, flow rate, operating pressure, available installation space, and the intended application. Ultratec’s technical team evaluates your requirements before recommending a suitable configuration.
Yes. Different filtration grades are available depending on the product type and application, allowing the system to remove suspended particles according to the required filtration level.
Yes. Disc Filters and Cluster Filters are commonly used as pretreatment before Reverse Osmosis systems to reduce suspended solids and help protect downstream equipment from excessive fouling.
These filtration systems are designed for continuous operation when correctly selected, installed, and maintained according to the application requirements.
Routine maintenance typically includes inspecting the filter housing, cleaning or replacing filter cartridges or disc elements when required, and monitoring system performance to maintain efficient filtration.
Yes. Ultratec provides installation support, commissioning assistance, maintenance services, and technical support for filtration systems across Dubai and the UAE.
Yes. Depending on the application, Ultratec can configure systems with different housing materials, cartridge arrangements, filtration ratings, connection sizes, and installation options.
Our combined FAQ section is more effective for a shared product page because it avoids repetitive content while naturally technical team evaluates your feedwater quality, flow requirements, operating conditions, and treatment objectives before recommending a suitable filtration solution for your project.
