Filmtec BW30-400 RO Membrane
DOW Filmtec BW30-400 RO Membrane 10500 GPD, an 8″ x 40″ high productivity brackish water Reverse Osmosis Membrane that can provide RO quality water up to 10,500 gallons per day at a 15% recovery rate. It can operate at feed pressures ranging from 225 psi to 600 psi with 99.5% salt rejection. This element offers the highest quality water for large-scale industrial and municipal water treatment systems purifying greater than approximately 10 gpm (2300 L/h) of RO water and is the industry standard for reliable operation and production of the highest quality water in commercial applications. It was the first 400 square foot membrane elements on the market and continues to be widely used in new equipment and retrofits where system capital and productivity are factors.
These elements are ideal for reverse osmosis plant managers and operators dealing with controlled pre-treatment and seeking consistent, high performance, long element life and increased productivity.
Filmtec elements can separate salts from water and are produced with an automated fabrication process for precision, consistency, and reliability offering high rejection of dissolved solids and organics and operate very efficiently at lower pressures. This minimizes equipment CAPEX in designs with savings in elements and pumping due to the 400 ft² active area while delivering the most effective cleaning performance, robustness and durability due to its widest cleaning pH range (1-13) tolerance. The 400 square feet(41 square meters) of active membrane area, gives system designers the option of designing a system with fewer membrane elements, requiring lower capital expenditures for membranes and components. This element is widely used in industrial water demineralization, production of municipal drinking water and water reuse.
Key Features and Benefits:
- 10,500 Gallons per day.
- 400 sq ft active area.
- 600 psi maximum operating pressure.
- Removes chemical contaminants.
- Reduce wastewater volumes by increasing water reuse.
- High flux results in high yields.
- Low energy costs with high rejection providing good water quality.
- Hard shell exterior for extra strength.
- Durable, can be cleaned for Long Element Life.
- DOW FilmTec high quality, long lasting and reliable performance.
Specifications:
| Model/SKU: | DWC64 |
| Manufacturer ID(Part#): | BW30-400 (Part #80610 ) |
| Dimensions(Diameter x Length): | 8 x 40(actual 7.9 x 40) |
| Stabilized Salt Rejection: | 99.5% |
| Permeate Flow Rate(Gallons per Day, gpd): | 10,500 Gal/Day * |
| Maximum Feed Flow Rate(Gallons per Minute, gpm): | 85 gpm (19.3 m3/hr) |
| Applied Pressure(psi): | 225 psi (15.5 bar) |
| Maximum Operating Pressure(psi): | 600 psi (41 bar) |
| Maximum Pressure Drop(psi): | 15 psi (1.0 bar) |
| Maximum Operating Temperature(°F): | 113°F (45°C) |
| pH Range, Continuous Operation: | 2 – 11 ** |
| pH Range, Short-Term Cleaning: | 1 – 13 |
| Maximum Feed Silt Density Index(SDI): | SDI 5 |
| Free Chlorine Tolerance(ppm): | < 0.1 ppm *** |
| Membrane Style: | Drop-in Element |
| Membrane Material: | Spiral-wound with Polyamide Thin-Film Composite |
| Active Area: | 400 ft² (37 m²). **** |
| Outer Wrap: | Hard fiberglass outer shell |
| Housing/Pressure Vessel Size(inch): | 8 inch |
Compatible Systems
- Industrial Brackish Water RO plants
- Municipal water treatment systems
- Water demineralization plants
- Industrial process water systems
- Water reuse and recycling systems
- Containerized RO plants
- Commercial RO systems
- 8-inch membrane pressure vessels
Modal
Features
Standard Features
- 8″ × 40″ spiral-wound thin-film composite RO membrane.
- Suitable for brackish water reverse osmosis applications.
- Produces up to 10,500 GPD permeate flow.
- 99.5% stabilized salt rejection.
- 400 ft² (37 m²) active membrane area.
- Operates at pressures up to 600 psi.
- Wide cleaning pH range of 1–13 for maintenance flexibility.
- Hard fibreglass outer wrap for mechanical strength.
- Designed for high productivity and long service life.
- Compatible with standard 8-inch pressure vessels.
Available Options
- Supply for new RO plant installations.
- Replacement membrane for existing RO systems.
- Individual or bulk quantity supply.
- Technical assistance for membrane selection.
Availability in UAE
Ultratec supplies FilmTec RO membranes for industrial and commercial reverse osmosis systems across Dubai, UAE, and the Gulf region. Membrane selection is based on feedwater analysis, system design, operating conditions, and required permeate quality.
Frequently Asked Questions
It is designed primarily for brackish water reverse osmosis applications in industrial and municipal water treatment systems.
Yes. It can be used as a replacement where the membrane dimensions and operating specifications are compatible with the existing RO system.
Feedwater quality, operating pressure, required permeate flow, recovery rate, and system configuration should all be evaluated before selection.
Membrane service life depends on feedwater quality, pretreatment effectiveness, operating conditions, and maintenance practices.
Yes. Ultratec supplies RO membranes and provides technical guidance for industrial, commercial, and municipal water treatment applications across the UAE and Gulf region.
